Product Introduction
PVC Flexible Ducting Hose is a flexible ventilation hose made of high-quality PVC material and a spiral reinforcement structure. It is specially designed for conveying air, smoke, dust and light particles, and is widely used in industrial ventilation, dust removal systems, HVAC equipment, agricultural ventilation and OEM equipment.
Technical parameters
|
Material |
100% Virgin PVC |
|
Frame |
Galvanized steel wire/stainless steel wire |
|
Inner Diameter |
25mm-600mm |
|
Wall Thickness |
0.4mm-2.0mm |
|
Length |
Customizable |
|
Operating Temperature |
-10℃～+70℃ |
|
Color |
Transparent, blue, gray, black, etc. |
|
Flame Retardant |
Customizable |
|
Antistatic |
Customizable |
Product Structure
PVC Flexible Layer
Made from high-quality, brand-new PVC raw materials.Flexible, wear-resistant, corrosion-resistant, and not prone to aging.
Spiral Reinforced Skeleton
Embedded with high-strength galvanized steel or stainless steel wire.Enhances support and prevents negative pressure collapse.
Smooth Inner Wall
The inner layer is flat and smooth.Reduces conveying resistance and improves ventilation efficiency.
Anti-aging Layer
UV-resistant formula can be added.Improves weather resistance and extends service life.
Product Features
High toughness: The flexible hose can be bent freely, adapting to complex installation environments, reducing the number of joints and improving construction efficiency.
Strong negative pressure resistance: The spiral steel wire reinforced structure effectively prevents duct deformation, ensuring continuous and stable ventilation.
Lightweight: Lighter than metal ducts, resulting in lower transportation, handling, and installation costs.
Abrasion and corrosion resistant: Suitable for dusty, exhaust gas, and general chemical environments, reducing replacement frequency.
High conveying efficiency: The smooth inner wall reduces airflow resistance, improving airflow output efficiency.
Flame retardant and antistatic customization available: Meets the special operating conditions of industrial dust removal, ventilation systems, and other applications.
Application Areas
Industrial Manufacturing: Workshop Ventilation and Exhaust; Air and Exhaust Gas
Woodworking Industry: Dust Removal Systems; Wood Chips and Dust
Metal Processing: Welding Fume Extraction; Smoke and Dust
HVAC Systems: Air Conditioning and Ventilation; Cool and Hot Air
Agricultural Greenhouses
Greenhouse Air Exchange; Air and Humidity
Chemical Industry
Exhaust Systems; Industrial Exhaust Gas
Construction Engineering
Temporary Air Supply; Air and Dust
Customized Services
Custom Sizes
Inner diameter, wall thickness, and length can be customized.
Custom Appearance
Colors, logos, coding, and packaging can be customized.
Custom Frames
Galvanized steel wire, stainless steel wire, and special reinforcement structures.
Custom Materials
Flame-retardant, antistatic, UV-resistant, and low-temperature resistant formulations.
FAQ
Q: Is it suitable for negative pressure ventilation systems?
A: Yes, the spiral reinforced structure effectively prevents negative pressure collapse.
Q: Is it made from virgin PVC raw materials?
A: We support production using 100% virgin PVC or specified formulas.
Q: Can you customize sizes and colors?
A: We support customization of pipe diameter, wall thickness, length, color, and packaging.
Q: Do you provide RoHS and REACH compliant products?
A: We can provide relevant standard products and test documents according to market requirements.
Q: What are the sample and lead time?
A: Samples take 3-7 days; lead time for bulk orders depends on quantity.
